Forget the technobabble and buzzword bingo for a sec. Here’s what Tyr is: a monstrous, old-skool, crazy heavy, over-the-top mono speaker amplifier. It uses the best of today’s and yesterday’s technologies to create something totally unique—and It has enough power to run almost anything.

Please note: "mono" means "one channel." You need two Tyrs for stereo.

Beyond Overbuilt

Nearly 25kgs. 5.45 Kgs choke. 160,000uf filter capacitance. 24 150W Toshiba output devices. 7 internal power supply rails, including HV boost rails that uses unique discrete CFP regulators. Sounds like overkill? It is. Tyr is our most insane amplifier ever, designed for driving difficult speakers without breaking a sweat.

Unique Nexus™ and Continuity™ Topology

Tyr is the ultimate expression of both Nexus and Continuity. In other words, this is a balanced, differential amplifier with a unique discrete, current-feedback gain stage, coupled with Continuity™ output topology that eliminates transconductance droop. In Tyr, we’ve refined Continuity even further, resulting in a cooler-running amplifier.

Back to the Past

One of the keys to Tyr’s performance is it’s huge inductor—literally the same size as the power transformer. This custom-made inductor is the “choke” in the “choke-input power supply.” This is a super old-skool technique you don’t see anymore, because chokes cost a mint and some people think banks of capacitors are more visually impressive.

Intelligent Oversight and Convenience

Like all of our amplifiers, Tyr is managed by a microprocessor running custom firmware. It monitors all operational parameters, from bias to temperature to DC, and protects the amplifier in case of any fault, for near-bulletproof reliability. Add the ability to put the amplifier into low-power “standby” mode on the front panel and switchable balanced and SE inputs, and Tyr is our most convenient amp ever.

Made in USA. Really.

By “made in USA,” we mean made in USA.

5-Year Warranty

Schiit Tyr is covered by a 5-year limited warranty that covers parts and labour.

Specs

Power Output:

8 Ohms: 200W RMS per channel maximum

4 Ohms: 350W RMS per channel maximum

Frequency Response: 20Hz-20Khz, -0.1db, 3Hz-500KHz, -3dB

THD: <0.01%, 20Hz-20KHz, at 200W RMS into 8 ohms

IMD: <0.01%, CCIR, at 200W RMS into 8 ohms

SNR: >120db, A-weighted, referenced to full output

Damping Factor: >200 into 8 ohms, 20-20kHz

Gain: 22 (28dB)

Input Sensitivity: AKA Rated Output (Vrms)/Rated Gain. Or, 40/22. You do the math.

Input Impedance: 47k ohms SE, 47k ohms balanced

Inputs: RCA for SE input, XLR for balanced input, rear panel switchable

Topology: Nexus™ discrete differential current feedback gain stage, no coupling capacitors or DC servos with Continuity™ constant transconductance output stage, all BJT output

Oversight: microprocessor-controlled monitoring and management of critical operational points, including DC offset, with standby mode and relay shut-down for overcurrent, thermal, and other faults

Power Supply: 600VA transformer with 600VA choke input to main rails, plus boosted, regulated supply to input, voltage gain and driver stages, plus separate, isolated and regulated rails for microprocessor management.

Power Consumption: 750W maximum

Size: 40.64 x 33.02 x 9.83 cm

Weight: 24.95 Kgs each
