Schiit Lyr+

Want a no-excuses, super-powerful, tube hybrid headphone amp and preamp—but also want the comfort of a pure solid state design? Then Lyr+ is for you! It’s the only headamp that goes seamlessly from tube to solid state, using Schiit's exclusive Fusion Architecture™.

I Can Live…With or Without Tube

( Unit Does Comes with Tube )

Don’t want to use a tube? Then don’t plug one in. Lyr+ switches seamlessly to its internal solid state gain stage, based on exotic depletion-mode MOSFETs. Want tube gain? Then plug in any 6SN7-type tube, and Lyr+ switches over to 100% tube voltage gain with the MOSFETs completely out of the picture. That’s the magic of Fusion Architecture.

Technological Tour De Force

Lyr+ is Schiit's first compact headamp that gives you relay ladder volume control, for ultimate transparency and perfect channel matching, from the lowest to highest volumes. Coupled with a powerful Continuity™ bipolar output stage, full DC coupling throughout, separate regulated high-voltage and low-voltage supplies, the convenience of remote control (in case you want to use it, say, off the desktop), and microprocessor oversight, Lyr+ is a small marvel.

Power and Safety in One

Lyr+ delivers up to 6W RMS per channel through the standard ¼” headphone jack, so there’s no need for balanced headphones to take advantage of all that power. But, at the same time, advanced oversight ensures Lyr+ is safe for every headphone. DC, overcurrent, and tube sensing means this is a fully modern tube amp.

The Heart of a Complete, Compact System

Add Bifrost 2 or Modius for digital duties, and a Vidar or Aegir as a speaker amp, and Lyr+ is the heart of a full system, ready for headphones, speakers, and both analog and digital sources. You can even turn off Lyr+’s preamp outs, if you just want to listen to headphones.

The vast majority of the production of the Lyr+ chassis, boards, assembly, etc—is manufactured in the US.

Most of the Schiit Lyr+ is covered by a limited warranty that covers parts and labour for three years. That's 3 years. Yes Three. Compare that to the competition.The parts that aren't covered by a 3-year warranty: the tubes. Tubes are covered by a 28-day warranty. They should last 5000 hours. Please note this doesn't mean free upgrades!


Solid State Mode, Low Gain

THD: < 0.0015%, 20Hz-20KHz, at 2V RMS, 32 ohms

IMD: < 0.001%, CCIR at 2V RMS, 32 ohms

SNR: > 115db, unweighted, referenced to 2V RMS

Crosstalk: < -72dB, 20Hz-20KHz, 32 ohms

Output Impedance: 0.4 ohms


Tube Mode, Low Gain

THD: < 0.003%, 20Hz-20KHz, at 2V RMS, 32 ohms

IMD: < 0.003%, CCIR at 2V RMS

SNR: > 111db, unweighted, referenced to 2V RMS

Crosstalk: < -70dB, 20Hz-20KHz, 32 ohms

Output Impedance: 0.4 ohms


Solid State Mode, High Gain

THD: < 0.003%, 20Hz-20KHz, at 2V RMS, 300 ohms

IMD: < 0.003%, CCIR at 2V RMS

SNR: > 102db, unweighted, referenced to 2V RMS

Crosstalk: < -85dB, 20Hz-20KHz

Output Impedance: 0.6 ohms


Tube Mode, High Gain

THD: < 0.004%, 20Hz-20KHz, at 1V RMS, 32 ohms

IMD: < 0.005%, CCIR at 1V RMS

SNR: > 97db, unweighted, referenced to 2V RMS

Crosstalk: < -85dB, 20Hz-20KHz

Output Impedance: 0.6 ohms


Preamp Output, Low Gain, Solid State

THD: < 0.0003%, 20Hz-20KHz, at 2V RMS

IMD: < 0.0003%, CCIR at 2V RMS

SNR: > 118db, unweighted, referenced to 2V RMS

Crosstalk: < -95dB, 20Hz-20KHz


Output Impedance: 75 ohms

Preamp Output, Low Gain, Tube

THD: < 0.0025%, 20Hz-20KHz, at 2V RMS

IMD: < 0.002%, CCIR at 2V RMS

SNR: > 112db, unweighted, referenced to 2V RMS

Crosstalk: < -90dB, 20Hz-20KHz

Output Impedance: 75 ohms


All Tube and Solid State Modes


Frequency Response: 20Hz-20Khz, +/-0.08db


Maximum Power, 16 ohms: 9.0W RMS per channel

Maximum Power, 32 ohms: 6.0W RMS per channel

Maximum Power, 50 ohms: 4.0W RMS per channel

Maximum Power, 300 ohms: 900mW RMS per channel

Maximum Power, 600 ohms: 450mW RMS per channel


Gain: High 5.7 (15dB), Low 1.2 (1.35dB)


Topology: Coherence ™ fully discrete, current-mode noninverting 6SN7/bipolar hybrid with constant transconductance output stage with Fusion Architecture™ depletion MOSFET gain fallback, 64-step relay ladder volume control.

Protection: microprocessor oversight for high DC, over-current, and tube presence; mute on any fault and management of tube and solid state gain modes.

Power Supply: two internal power transformers with 72VA total rating, plus with over 55,000uf of filter capacitance; two discrete regulated +/-100V supplies, two high-current +/-26V supplies, four regulated oversight supplies—20V, +/-15V, 5V

Power Consumption: 30W

Size: 22.86 x 15.24 x 5.08 cm

Weight: 2.27Kgs
